Products > BS336 Stroboscope LED RGB+W Combi

BS336 Stroboscope LED RGB+W Combi

beamZ

153.289
  • Stroboscope, Blinder and Wash fixture
  • 280x RGB SMD LEDs
  • 56x White SMD LEDs
  • RGB + White colour mixing
  • Controllable in 12 segments (8 RGB and 4 White LED zones)
  • DMX512, stand alone and Master/slave Mode
  • Automatic programs and Pre-programmed shows
  • Adjustable speed 1-15
  • Fan cooled ABS housing
  • Various dimmer curves adjustable
  • IEC Power input
  • Wireless remote control
Specifications
Product colour Black
Light source Single colour LED, 3-in-1 LED
Colours Red, Green, Blue, White
Quantity of LEDs 336
Quantity of strobe LEDs 56
Beam angle 60°
Field angle 112°
Illuminance 2.126 lx @ 0.5m
Flash rate per second 1 - 20Hz
DMX channels 4, 6, 12, 24, 30
DMX connection 3-pin XLR
Modes Automatic programs, DMX, Master/Slave
IP rating IP20
Cooling Temperature controlled fan
Display LED
Power plug IEC
Power consumption 0.425 - 0.262A
Power supply 100-240VAC 50/60Hz
Dimensions (L x W x H) 265 x 160 x 65mm
Weight (kg) 0.9500
Included accessories Remote control (wireless), Mounting bracket

The BS336 is a powerful multi-use fixture and is specially designed to be used as a strobe, blinder or wash, thanks to the 336 SMD LEDs. The LED panel is divided in different sections and can flash in any colour you desire thanks to its RGB mixing system. This fixture is also equipped with a strip of 56 white SMD LEDs in the centre of the fixture, controllable in different sections to create the traditional look of a strobe. The BS336 makes it possible to create unique colourful effects and control is easy via DMX or in stand-alone mode with automatic function. Suitable for all kind of shows and events.

Downloads
