LCB140 LED Bar 12x 6W

beamZ

150.703
  • 12x 6W 4-in-1 LEDs
  • RGBW Colour mixing
  • Colour presets
  • Pre programmed shows
  • Electronic Dimming: 0 – 100%
  • 2, 3, 4 or 8 DMX channels
  • DMX and Stand-alone mode
  • Master/slave function
  • Sound activated with adjustable sensitivity
  • Auto mode with adjustable speed
  • DMX in/output via 3-pin XLR
  • Control panel with LED display
  • Aluminium housing
  • IEC-connector input/output
Specifications
Product colour Black
Light source 4-in-1 LED
LED colours Red, Green, Blue, White
LED power (single LED) 6W
Quantity of LEDs 12
Beam angle 53° x 19°
Field angle 68° x 32°
Illuminance 2.100lx
DMX channels 2, 3, 4, 8
DMX connection 3-pin XLR
Modes Automatic programs, DMX
Daisy chain Yes (max. 6 bars)
IP rating IP20
Power plug IEC
Power consumption 25W
Power supply 100-240VAC 50/60Hz
Dimensions (L x W x H) 1025 x 65 x 65mm
Weight (kg) 3.2500

The LCB140 is a LED bar with 12 pieces RGBW LEDs. The LEDs are divided in 1 controllable section. While using the fixture in stand-alone mode there are pre-programmed shows that you can run automatically or sound activated. The extra IEC output enables you to simply link the power of multiple units together into a single socket.
