MHL820 Double Helix 8x 3W RGBW LEDs DMX


  • 8x 3W CREE LEDs
  • DMX and stand-alone mode
  • Sound activated with adjustable sensitivity
  • Auto mode with adjustable speed
  • Pre programmed shows
  • 0 – 100% dimming and variable strobe speed
  • DMX in/output via 3-pin XLR
  • Control panel with LED display
  • IEC Connector input
Product colour Black
Light source Single colour LED
LED colours Red, Green, Blue, White
LED power (single LED) 3W
Quantity of LEDs 8
DMX channels 7, 15
DMX connection 3-pin XLR
Head movement: Tilt 135
Modes Automatic programs, DMX
Power supply 100-240VAC 50/60Hz
Dimensions (L x W x H) 280 x 150 x 135mm
Weight (kg) 1.4500

The MHL820 double Helix is a popular LED effect. Due to its shape the MHL820 double Helix produces a wide spread. The 2 separated strokes with each 4x 3W CREE LEDs will rotated separately for an amazing light effect. Both channels provide strobe effect. Ideal for use as front light on stage, disco installations, mobile set-ups etcetera.
