Fuze Twin LED Spot Moving Head Bar

150.388

Moving heads: 75W High Intensity White LED
LED T-Bar: 6x 15W RGBW LEDs
DMX and Stand-alone mode
Beam angle: 12° with manual focus
Gobo Wheel: 7x fixed metal gobos + open
Colour wheel: 8 colours + open
0-100% Electronic Dimmer
User-selectable pan and tilt
Strobe: 1-16Hz
Master/slave synchronization
Sound activated with adjustable sensitivity
9 Auto programs and 9 Sound programs
Control panel with LCD display
DMX in/output via 3-pin XLR
P-Con input/output
Two handles for easy transport

Specifications

Specifications
Description
Videos
Download & links

Product colour	Black
Light source	Single colour LED, 4-in-1 LED
Colours	Red, Green, Blue, White
LED power (single LED)	15W, 75W
Quantity of LEDs	2 + 6
Colour wheel	8 colours + open
Beam angle	9°
Field angle	11°
Illuminance	55.198 lx @ 1m
Head movement: Pan	540°
Head movement: Tilt	180°
Static gobo: Quantity	7
Flash rate per second	1 - 22Hz
Modes	Automatic programs, DMX, Master/Slave
Sound to light mode	Yes
DMX channels	18, 28, 52
DMX connection	3-pin XLR
Display	LCD
IP rating	IP20
Cooling	Temperature controlled fan
Power plug	P-Con
Power consumption	2.49 - 1.31A
Power supply	100-240VAC 50/60Hz
Dimensions (L x W x H)	570 x 143 x 330mm
Weight (kg)	8.8500
Included accessories	Remote control (wireless), Mounting bracket, Power cable

The Twin LED Moving Head Bar consists of 2 individual moving heads mounted on a sturdy metal T-bar that is also equipped with 6 high power RGBW LEDs. The two moving heads are equipped with a 75W LED and can be independently controlled via DMX, allowing you to tailor your lighting effects with unparalleled precision. In addition to DMX control, this fixture offers a range of automated features. Engage the various automatic programs to effortlessly transform your venue with captivating light patterns. For those who prefer a hands-free experience, the fixture includes a sound-to-light mode, syncing its movements and colors to the beat of the music, adding an extra layer of excitement to any event. Link multiple units together with P-Con and DMX in and outputs. The Twin LED Moving Head Bar can be mounted on a standard 35mm stand.
