Pollux 2500 Analog Laser System


  • Powerful 2,5W analog animation laser
  • Red (600mW), Green (800mW) and Blue (1100mW) laser modules
  • 25K high speed optical scanner system
  • DMX and Stand-alone mode
  • 17 DMX channels
  • Master/slave function
  • Sound activated with adjustable sensitivity
  • Auto mode
  • Preprogrammed patterns and animations
  • DMX in/output via 3-pin XLR
  • ILDA in/output
  • Control panel with LCD display
  • Incl. 2GB SD Card and remote control
Product colour Black
Input connections SD
DMX channels 17
DMX connection 3-pin XLR
Laser Red 600mW @ 638nm
Laser Green 800mW @ 520nm
Laser Blue 1100mW @ 450nm
Scanner system 25kpps @ 8°
Guaranteed output (99mW) 2000mW
Maximum output (99mW) 2500mW
Power consumption 0.594 - 0.294A
Power supply 100-240VAC 50/60Hz
Dimensions (L x W x H) 215 x 215 x 191 mm
Weight (kg) 2.6000

The Pollux 2500 is a DMX Super animation laser with over hundred incorporated effects on the enclosed SD card. The Pollux 2500 features an analog modulation. Basically, it allows you to display up to 16.7 million colour tones and “dim” the output of the laser beam. On the back you will find a DMX in/output with 3-pin XLR and an ILDA in/out connection. An ILDA connector is the standard connector for show laser lights that connect the laser display with an ILDA cable to the laser control device. When using a DMX controller the Pollux laser offers 17 DMX channels in DMX mode. It’s also possible to set the Pollux 2500 into a sound-activated mode with the built-in microphone on the back of the laser. Including a 2GB SD card and remote control.
